No.5000 F
니하치 프로 · 니하치 · 니하치프로 · nihachi · Nihachi Pro No.5000 F · 28pro No.5000 F · N°5000 F · N5000F · No.5000"F" · No.5000 F 코팅 · 니하치 프로 No.5000 F · 28프로 No.5000 F · ナノダイヤモンドコーティング No.5000 · 나노다이아몬드 코팅 No.5000 F · 5000 F 2단계 코팅
No.5000 F is a two-step nano-carbon paint coating system. Step 1 is a nano-diamond-infused hard glass coating that delivers crystal-clear gloss, improved film hardness, and superior anti-fouling properties. Step 2 is a carbon nanotube sacrificial overcoat with anti-static and anti-fouling agents that further protects Step 1, reduces water-spot formation, and helps maintain airflow across the body surface.
No.5000 F는 2단계 나노카본 도장 코팅 시스템입니다. Step 1은 나노다이아몬드 배합의 경화형 글라스 코팅으로 극투명한 광택과 피막 강도, 방오성을 제공합니다. Step 2는 카본나노튜브와 대전 방지제를 배합한 희생피막 오버코팅으로, Step 1을 보호하고 물자국 형성을 억제하며 차체 표면의 기류를 정돈하는 효과를 기대할 수 있습니다.
- Brand
- Nihachi Pro
- Categories
- Exterior : Coating
Key features
- Two-step system: nano-diamond hard coat (Step 1) + carbon nanotube sacrificial overcoat (Step 2)
- Step 1 nano-diamond formula enhances film hardness, clarity, and anti-fouling performance
- Step 2 carbon nanotube layer provides anti-static discharge and advanced anti-fouling
- Steps 1 and 2 must be applied consecutively without interruption
- Water-bead performance: super-hydrophobic (ultra water-beading)
- Durability: 3 years or more for the hard coat layer
- Surface cure in approximately 2 hours; full cure in 2 days; gloss stabilizes around 7 days
- Applicable to painted body surfaces and most exterior surfaces
Usage
- Wash the vehicle and remove all contaminants. Wipe off all moisture. Perform adequate paint decontamination and surface preparation — coating performance depends heavily on prep quality.
- Prepare cloths: applicator (MF sponge), wipe-off cloth, and finishing cloth (plus 2 spares). Mask any areas you do not want coated (rubber, glass, etc.) if desired.
- Shake Step 1 (Nano Diamond Hard Coating) vigorously about 50 times to disperse the nano-diamond particles.
- Apply Step 1 in dry conditions only. Start with approximately 10 drops on the applicator sponge, then add 2–3 drops per panel as you proceed. Work one panel at a time: apply, wipe off evenly, finish with the finishing cloth.
- For large panels (hood, roof), divide into four sections and complete each section before moving on. Do not rest mid-application — any missed areas will harden and become difficult to remove.
- Immediately after completing Step 1, proceed to Step 2 (Carbon Nanotube Coating) without delay.
- Shake Step 2 approximately 30 times (floating black particles are carbon nanotubes — shake well). Spray onto a damp, well-wrung cloth.
- Working one panel at a time, spread Step 2 across the panel, then wipe clean with a separate damp, well-wrung cloth to remove streaks. Finish with a dry wipe for best results.
- After completing both steps, perform a final check across the entire vehicle for any uneven areas or streaks. Address any issues promptly before curing progresses.
- Work in the shade, away from direct sunlight, wind, and high heat. Wear protective gloves, mask, and goggles throughout.
핵심 특징
- 2단계 시스템: 나노다이아몬드 경화 코팅(Step 1) + 카본나노튜브 희생피막 오버코팅(Step 2)
- Step 1 나노다이아몬드 포뮬라로 피막 강도·투명도·방오성 향상
- Step 2 카본나노튜브 레이어로 대전 방지 및 고방오성 구현
- Step 1과 Step 2는 중단 없이 연속으로 시공해야 함
- 발수 성능: 초발수계 (물방울 구슬 현상)
- 내구성: 경화 피막 3년 이상
- 표면 경화 약 2시간, 완전 경화 2일, 광택 안정화 약 7일
- 도장면 및 주요 외장 부위에 적용 가능
사용법
- 차량을 세차하여 오염물을 제거하고 수분을 완전히 닦아냅니다. 철저한 전처리 및 하지 처리를 실시하세요 — 코팅 성능은 전처리 품질에 크게 좌우됩니다.
- 클로스를 준비합니다: 도포용(MF 스펀지), 닦아내기용, 마무리용 각 1장씩과 예비 2장. 필요에 따라 고무류, 유리면 등 코팅을 원하지 않는 부위를 마스킹하세요.
- Step 1(나노다이아몬드 경화 코팅)을 약 50회 힘껏 흔들어 나노다이아몬드 성분을 분산시킵니다.
- Step 1은 반드시 건식으로 시공합니다. 도포용 스펀지에 처음 10방울 정도 떨어뜨려 시작하고, 이후 패널마다 2~3방울씩 추가합니다. 한 패널씩 도포→고르게 닦아냄→마무리 클로스로 마감합니다.
- 보닛·루프 등 넓은 패널은 4등분하여 구역별로 시공합니다. 중간에 쉬지 마세요 — 놓친 부위가 굳어 제거가 어려워집니다.
- Step 1 시공이 완료되는 즉시, 지체 없이 Step 2(카본나노튜브 코팅) 시공을 진행합니다.
- Step 2를 약 30회 흔듭니다(떠다니는 검은 입자가 카본나노튜브이므로 충분히 흔들어 섞어주세요). 물에 적셔 꼭 짠 클로스에 스프레이로 분사합니다.
- 한 패널씩 Step 2를 고르게 도포한 후, 물에 적셔 꼭 짠 깨끗한 클로스로 얼룩 없이 닦아냅니다. 마지막에 건식 닦기를 하면 마감이 더욱 좋아집니다.
- 두 단계 시공이 완료되면 차량 전체를 최종 점검하여 얼룩이나 불균일한 부분을 확인·제거합니다. 경화가 진행되기 전에 신속히 처리하세요.
- 직사광선, 바람, 고온을 피해 그늘에서 시공하며, 전 공정에서 보호 장갑·마스크·보안경을 착용하세요.
